Servocut Series

SERVOCUT Series



SERVOCUT is the perfect choice for a wide range of materials and for heavy duty cutting applications. It combines the two well proven cutting techniques into the same machine:



Chop cutting: The specimen is clamped and the cut-off wheel approaches the specimen via a rocker arm.

Table-feed cutting: Feeding the clamped specimen into a rotating cut-off wheel using a slotted feed table.



The workpiece to be cut can be accurately positioned in 3 axis which is displayed digitally on the front panel.

SERVOCUT is available in three main sizes and in automatic and/or manual versions:



SERVOCUT 302MM/MA/AA: Medium Size (cut-off wheel dia.of 250/300 mm)

SERVOCUT 402MM/MA/AA: Large Size (cut-off wheel dia.of 350/400 mm)

SERVOCUT 502: Very Large Size (cut-off wheel dia.of 450/500 mm)

SERVOCUT 602: Multi target automatic abrasive cutting machine ( cut off wheel dia of 600mm )



All Servocut series have variable rotational speed option for optimum cutting, and cutting different various of materials without changing cut off wheel.

Available with optional Cutting Methods including Diagonal Cut, Step Cut and Segment Cut.



Diagonal Cut: for increased cutting capacity

Step Cut: for extra hard materials

Segment Cut: for difficult workpieces.



Servocut Series includes a standard set of cutting consumables composed of;  An assortement of 20 cut-off wheels and 5 lt of Metcool cooling fluid.



Download Catalogue
SERVOCUT 302 MM



Description
Abrasive Cutting Machine

With hand wheel driven chop cutting and table-feed cutting systems, manual positioning of the specimen in X and Y axis (X-axis for plane parallel cutting is optional),  manual positioning of the cutting wheel in Z-axis, powerful 4 kW cutting motor, 2850 rpm cutting speed, with electronic brake system, cutting  capacity up to 110/90 mm solid stock, with cut-off wheels up to ø300/250mm, twin T-slotted clamping table made of stainless steel,  bottom part as rugged alloy base casting, extraordinary access for easy handling with sliding door and side openings, Ready  for operation. Without clamping devices, without recirculation cooling tank.
Includes a standard set of cutting consumables composed of;
*An assortment of 20 cut-off wheels with 300 mm dia.
*5 lt of Metcool cooling fluid.
400 V, 3 phase, 50/60 Hz.



Download Catalogue
SERVOCUT 302 MA

Description
Automatic Abrasive Cutting Machine

Programmable with 7" HMI touch screen control, with Siemens PLC control unit, with hand wheel driven chop cutting and  automatic driven table-feed cutting  systems,  with various cutting methods, programmable with colored LCD display of cutting parameters, accurate and motorized positioning of the specimen in X  and Y axis (X-axis for plane parallel cutting is optional), ergonomic joystick with adjustable speed control, integrated feed path control, power dependent adjustable feed rate, variable cutting force, pulse cutting mode, bar graph overload display, powerful 4 kW cutting motor, with variable cutting speed 600-4000 rpm, with electronic brake system, cutting capacity up to 110/90 mm solid stock, with cut-off wheels up to ø300/250mm, twin T-slotted table(Y-direction only) made of stainless steel, bottom part as rugged alloy base casting, extraordinary access for easy handling with sliding door and side openings, with extra advanced cutting methods: "Rapid Pulse Cutting, Instafeed Cutting,  Automatic Table Feed Cutting, Joystick Cutting"  Ready  for operation. Without clamping devices, without recirculation cooling tank.
Includes a standard set of cutting consumables composed of;
*An assortment of 20 cut-off wheels with 300 mm dia.
*5 lt of Metcool cooling fluid.
400 V, 3 phase, 50/60 Hz.



Download Catalogue
SERVOCUT 302 AA

Description
Automatic Abrasive Cutting Machine

Programmable with 7" HMI touch screen control, with Siemens PLC control unit, with automatic chop cutting and automatic table-feed cutting  systems,  with various cutting methods, programmable with colored LCD display of cutting parameters, accurate and motorized positioning of the specimen in X - Y and Z axis (X-axis for plane parallel cutting is optional), ergonomic joystick with adjustable speed control, integrated feed path control, power dependent adjustable feed rate, variable cutting force, pulse cutting mode, bar graph overload display, powerful 4 kW cutting motor, with variable cutting speed 600-4000 rpm, with electronic brake system, cutting capacity up to 110/90 mm solid stock, with cut-off wheels up to ø300/250mm, twin T-slotted table(Y-direction only) made of stainless steel, bottom part as rugged alloy base casting, extraordinary access for easy handling with sliding door and side openings,
with extra advanced cutting methods: "Rapid Pulse Cutting, Table Oscillation Cutting, Instafeed Cutting, Automatic Chop Cutting, Automatic Table Feed Cutting, Joystick Cutting" Ready  for operation.
Without clamping devices, without recirculation cooling tank.
Includes a standard set of cutting consumables composed of;
*An assortment of 20 cut-off wheels with 300 mm dia.
*5 lt of Metcool cooling fluid.
400 V, 3 phase, 50/60 Hz.





Download Catalogue
SERVOCUT 402 MA

Description
Automatic Abrasive Cutting Machine

Programmable with 7" HMI touch screen control, with Siemens PLC control unit, with hand wheel driven chop cutting and automatic driven table-feed cutting  systems,  with various cutting methods, programmable with colored LCD display of cutting parameters, accurate and motorized positioning of the specimen in X  and Y axis (X-axis for plane parallel cutting is optional), ergonomic joystick with adjustable speed control, integrated feed path control, power dependent adjustable feed rate, variable cutting force, pulse cutting mode, bar graph overload display, powerful 7.5 kW cutting motor, with unique belt protection system, with variable cutting speed 600-3200 rpm, with electronic brake system,
cutting capacity up to 150/130 mm solid stock, with cut-off wheels up to Ø400/350mm, twin T-slotted table(Y-direction only) made of stainless steel, bottom part as rugged alloy base casting, extraordinary access for easy handling with sliding door and side openings, with extra advanced cutting methods:
"Rapid Pulse Cutting, Instafeed Cutting, Automatic Table Feed Cutting, Joystick Cutting"
Ready  for operation. Without clamping devices, without recirculation cooling tank.
Includes a standard set of cutting consumables composed of;
*An assortment of 20 cut-off wheels with 400 mm dia.
*5 lt of Metcool cooling fluid.
400 V, 3 phase, 50/60 Hz.



Download Catalogue
SERVOCUT 402 AA

Description
Automatic Abrasive Cutting Machine

Programmable with 7" HMI touch screen control, with Siemens PLC control unit, with automatic chop cutting and automatic table-feed cutting  systems,  with various cutting methods, programmable with colored LCD display of cutting parameters, accurate and motorized positioning of the specimen in X - Y and Z axis (X-axis for plane parallel cutting is optional), ergonomic joystick with adjustable speed control, integrated feed path control, power dependent adjustable feed rate, variable cutting force, pulse cutting mode, bar graph overload display, powerful 7.5 kW cutting motor, with unique belt protection system, with variable cutting speed 600-3200 rpm, with electronic brake system, cutting capacity up to 150/130 mm solid stock, with cut-off wheels up to Ø400/350mm, twin T-slotted table(Y-direction only) made of stainless steel, bottom part as rugged alloy base casting, extraordinary access for easy handling with sliding door and side openings, with extra advanced cutting methods: "Rapid Pulse Cutting, Table Oscillation Cutting, Instafeed Cutting, Automatic Chop Cutting, Automatic Table Feed Cutting, Joystick Cutting" Ready  for operation. Without clamping devices, without recirculation cooling tank.

Includes a standard set of cutting consumables composed of;
*An assortment of 20 cut-off wheels with 400 mm dia.
*5 lt of Metcool cooling fluid.
400 V, 3 phase, 50/60 Hz.



Download Catalogue
SERVOCUT 502

Description
Automatic Abrasive Cutting Machine

Programmable with 7" HMI touch screen control, with Siemens PLC control unit, with automatic chop cutting and automatic table feed cutting systems, with various cutting methods, programmable with colored LCD display of cutting parameters, accurate and motorized positioning of the specimen in X - Y and Z axis (X-axis for plane parallel cutting is optional), ergonomic joystick with adjustable speed control, integrated feed path control, power dependent adjustable feedrate, variable cutting force, rapid pulse cutting mode, bar graph overload display, powerful 11 kW cutting motor, with unique belt protection system, with variable cutting speed 600-2400 rpm, with electronic brake system, cutting capacity up to 180/130 mm solid stock, with cut-off wheels up to Ø500/400 mm, twin T-slotted table
(Y-direction only) made of stainless steel, bottom part as rugged alloy base casting, extraordinary access for easy handling with sliding door and side openings, with extra advanced cutting methods:
"Rapid Pulse Cutting, Table Oscillation Cutting, Instafeed Cutting, Automatic Chop Cutting, Automatic Table Feed Cutting, Joystick Cutting" Ready  for operation. Without clamping devices, without recirculation cooling tank.
Includes a standard set of cutting consumables composed of;
*An assortment of 20 cut-off wheels with 500 mm dia.
*5 lt of METCOOL cooling fluid.
400 V, 3 phase, 50/60 Hz.





Download Catalogue
Servocut 602-AX

Description
Multi-Target Automatic Cutting Machine

For cutting large and multiple specimens, ability to work with cut-off wheels up to Ø600 mm, cutting capacity up to Ø225 mm solid stock, 100Hx500D mm for rectangular specimens (cutting capacity can be increased up to 200Hx550D mm with optional Combined Cut feature), powerful 15 kW cutting motor
with unique belt protection system, with electronic brake system, with variable cut-off wheel speed 600-2400 RPM, ability to set fixed peripheral speed of cut-off wheel from 20 to 60 m/s, overload display and protection system, accurate Servo motor driven table and wheel movement for precise and fast positioning, joystick with adjustable speed control, stainless steel table (772x710mm) with 560 mm Y-axis movement range, Servo motor driven cut-off wheel positioning system on X-axis, 540 mm positioning range on X-axis, including advanced cutting methods:"Serial Parallel Cutting" for slicing multiple pieces from a specimen automatically in one cycle. "Multi Target Cutting" for cutting up to 20 different clamped specimens on the table to be cut  automatically in one cycle.
Programmable with9.7" HMI touch screen control, Siemens PLC control unit, automatic cut-off wheel diameter measurement and automatic starting position adjustment according to cut-off wheel wear,
Positioning System allows clamping several components simultaneously, with automatic chop cutting and automatic table feed cutting  systems, with automatic cutting feedrate control, with extra advanced cutting methods: "Multi-Target Cutting, Serial Parallel Cutting, Rapid Pulse Cutting, Table Oscillation Cutting, Instafeed Cutting, Automatic Chop Cutting, Automatic Table Feed Cutting, Joystick Cutting"  Powerful LED illumination, robust construction.

Ready for operation.
Without clamping devices, without recirculation cooling tank.
Includes a standard set of cutting consumables composed of;
*An assortment of 10 cut-off wheels with 600 mm dia.
*5 lt of METCOOL cooling fluid.
400 V, 3 phase, 50/60 Hz.



Download Catalogue
Servocut 602-AX-R with Rotary Table

Description
4-Axis Multi-Target Automatic Cutting Machine

SERVOCUT 602-AX-R is designed for cutting complex shaped specimens in any angle without re-clamping.

• Equipped with 360° rotary table with servo motor drive
• Ability to cut specimens up to 20 different cutting lines in different angles
• Program memory for cutting lines and parameters for Multi-Target
Cutting.

SERVOCUT 602-AX-R combines the most advanced cutting techniques in the same machine. Equipped with the large automated rotary table that eliminates re-clamping, saves time and provides maximum automation. Servo motor driven rotary table allows very precise angle positioning. Save setup time by storing up to 20 cutting lines with different angles which can be recalled at any time for quick and easy loading.

4-axis cutting is the fastest way to reduce setups, boost throughput, and increase accuracy on complex parts. The angle of rotary table can be adjusted with 0.1° accuracy. With combination of all 4-axis, the cutting can be done in any possible position without re-clamping.
