Precision Cutter Series





Precision Cutting

Precision cutting is used for precise and deformation-free cutting of  “Metals, Ceramics, Electronic Components, Crystals, Composites, Biomaterials, Sintered Carbides, Minerals, etc.


Download Catalogue
MICRACUT 152

Description
Precision Cutter

Modern touch-pad controls with digital display, ergonomic turn knob for fast and easy setting of parameters, 100 W powerful DC cutting motor, variable speed 50-1500 rpm, with digital micrometer cross feed for specimen positioning, counterbalanced sliding weight system, removable cooling unit, automatic cut-off switch, transparent protection hood with magnetic safety switch, for cutting discs of up to 175 mm diameter. Ready for operation. Without specimen vises. 230 V, 50 Hz, AC.
Includes a standard set of cutting consumables composed of;
*1 pc. Diamond cutting Disc 150 mm dia.
*1 lt of METCOOL II cooling fluid.





Download Catalogue
Micracut 200-S

Description
Automatic High-Speed Precision Cutter

Programmable with 7" HMI touch screen control, with Siemens PLC control unit, with motorized cutting system, automatic or manual cutting modes, motorized precise grinding with 5 microns accuracy, accurate positioning of the specimen in X-axis with 5 microns positioning accuracy, 0-50 mm positioning range in X-axis with readout on HMI touch screen, smart guide for X-axis positioning, integrated feed path control, power dependent adjustable feedrate, variable cutting force, rapid pulse cutting mode, bar graph overload display, powerful 0.55 kW cutting motor, with variable cutting speed 100-5000 rpm, with electronic brake system, cutting capacity  up to 75 mm solid stock, with cut-off wheels up to Ø200 mm or diamond cup grinding wheels up to Ø175 mm, with built-in dressing unit, with built-in removable cooling unit, transparent protection hood, with extra advanced cutting methods, Ready  for operation.
Includes a standard set of cutting consumables composed of;
*1 pc. Diamond cutting Disc 200 mm dia.
*1 lt of Metcool II cooling fluid.
230 V, 50/60 Hz, AC.

Technical Specifications

Order No 16 07

Model MICRACUT 200-S
Cut-off Wheel Diameter, (mm) up to Ø200 mm
Cutting Capacity, Ø (mm) Ø75 mm
Sample Movement in Z-Axis Motorized
Sample Movement in X-Axis Manual
X-Axis Positioning Range, (mm) 0-50 mm
X-Axis Positioning Accuracy, (μm) 5 μm
Cutting Feed Speed, (μm/s) 5 - 10000 μm/s
Cutting Motor Power, (kW) (S1) 0.55 kW
Disc Speed, (RPM) 100 – 5000 RPM
Control Panel 7" HMI Touch Screen
Program Capacity 99 Program Memory
Cutting Modes Automatic Cutting in Z-Axis
Manual Cutting in Z-Axis
Manual Table-Feed Cutting in Y-Axis
Pulse Cutting Yes (Rapid Pulse Cutting)
Automatic Feedrate Yes (Instafeed Cutting)
Multi-Section Cutting Yes (Hybrid Cutting)
Parallel Cutting, X-Axis Yes (Semi-Automatic)
Precise Grinding Feature Yes (Manual/Semi-Automatic)
Grinding Wheel Diameter, (mm) Ø175 mm
Grinding Feed Speed, (μm/s) 500 - 50000 μm/s
Cooling Unit, (lt) 4.5 lt (integrated)
Illumination LED
Dressing During Cutting Operation Yes
Motor Drive System Direct Drive
Dimensions, WxDxH, (mm) 640 x 732 x 529h mm
Weight 90 kgs

Download Catalogue
MICRACUT 202

Description
Automatic High Speed Precision Cutter

Programmable with 7" HMI touch screen control, with Siemens PLC control unit, with automatic  table feed cutting system, programmable with colored LCD display of cutting parameters, accurate and motorized positioning of the specimen in X - Y and Z axis with digital readout on the LCD (X-axis for plane parallel cutting is optional), ergonomic joystick with adjustable  speed control, integrated feed path control, power dependent adjustable feedrate, variable cutting force, rapid pulse cutting mode, bar graph overload display, powerful 1.1 kW cutting motor, with variable cutting speed 100-5000 rpm,
with electronic brake system, cutting capacity  up to 75 mm solid stock, with cut-off wheels up to Ø200 mm, twin T-slotted table (Y-direction only) made of stainless steel, bottom part as rugged alloy base casting, extraordinary access for easy handling with sliding door and side openings, ability to mount diamond cup grinding wheel for thin section, with built-in recirculation cooling unit, with extra advanced cutting methods:  "Rapid Pulse Cutting, Instafeed Cutting, Automatic Table Feed Cutting" Ready  for operation. 230 V, 50/60 Hz, AC.
Includes a standard set of cutting consumables composed of;
*1 pc. Diamond cutting Disc 200 mm dia.
*10 abrasive thin cut-off wheels 200 mm dia.
*1 lt of Metcool II cooling fluid.
